Overview

8 9
7
10 11 12
(1) LED
(2) Microphone
(3) Display
1
(4) Safety bond hole
(5) Control Board
2
(6) Charge indicator
3
(7) Mode button
4
(8) Up button
(9) Down button
5
(10) Function button (WDMX)
6
(11) Enter button
(12) Fixation folding foot
(13) Carrying handle
(14) Infrared sensor for the remote
control
(15) Mounting thread
(16) Folding foot
(17) 3-pin DMX input
(18) 3-pin DMX output
(19) Power switch
(20) Fuseholder
(21) Power input
(22) Power output
27/40 00088947.DOC, Version 1.1
