EuroLine AKKU UP-4 HCL Spot WDMX Bedienungsanleitung Seite 38

111 130 6F 82 44% 51%
131 150 83 96 51% 59%
151 170 97 AA 59% 67%
171 200 AB C8 67% 78%
201 205 C9 CD 79% 80%
206 210 CE D2 81% 82%
211 215 D3 D7 83% 84%
216 220 D8 DC 85% 86%
221 225 DD E1 87% 88%
226 230 E2 E6 89% 90%
231 235 E7 EB 91% 92%
236 240 EC F0 93% 94%
241 245 F1 F5 95% 96%
246 250 F6 FA 96% 98%
251 255 FB FF 98% 100%
Decimal Hexad. Percentage S/F
0 10 00 0A 0% 4%
11 60 0B 3C 4% 24%
61 120 3D 78 24% 47%
121 180 79 B4 47% 71%
181 240 B5 F0 71% 94%
241 255 F1 FF 95% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
0 10 00 0A 0% 4%
11 255 0B FF 4% 100%
Decimal Hexad. Percentage S/F
0 51 00 33 0% 20%
52 101 34 65 20% 40%
102 152 66 98 40% 60%
153 203 99 CB 60% 80%
204 255 CC FF 80% 100%
F RED 100% / GREEN 0% / BLUE decreasing
F RED 100% / GREEN increasing / BLUE increasing
F RED decreasing / GREEN decreasing / BLUE 100%
F RED 100% / GREEN 100% / BLUE 100% / WHITE 100%
S WHITE color temperature 1
S WHITE color temperature 2
S WHITE color temperature 3
S WHITE color temperature 4
S WHITE color temperature 5
S WHITE color temperature 6
S WHITE color temperature 7
S WHITE color temperature 8
S WHITE color temperature 9
S WHITE color temperature 10
S WHITE color temperature 11
Control-channel 10 - Internal programs
S No function
S Internal program 1
S Internal program 2
S Internal program 3
S Internal program 4
S Music control
Control-channel 11 - Speed internal programs /
microphone sensitivity
F Increasing speed
S No microphone sensitivity
F Microphone sensitivity between 0 % and 99 %
Control-channel 12 - Dimmer speed (step response)
S Control Board setting dimmer speed
S Neutral
S Dimmer speed 1
S Dimmer speed 2
S Dimmer speed 3
38/40
warm
cold
Feature
Feature
Feature
00088947.DOC, Version 1.1
