Operating Principle; Scope Of Supply - Fronius Modbus Card Bedienungsanleitung

Operating princi-
ple
(1)
(2)
(3)

Scope of Supply

(1) (2)
30
(1)
1230 W
Modbus Card
(Slave)
Inverter 1
Inverter 2
Inverter 3
(3)
(2)
3120 W
Modbus Card
(Slave)
(4)
(5)
(1)
(2)
(3)
(3)
2310 W
(4)
Modbus Card
(Slave)
(5)
Fronius Solar Net termination plug
Modbus connection
1 x Fronius Modbus Card
1 x 6-pin plug for connection to the
Modbus system
2 x Fronius Solar Net terminating
plugs
Not pictured:
1 x operating instructions
1 x carton packaging (only for Froni-
us Modbus Card upgrades)
The other components for the
Fronius Modbus Card installed in
the inverter are included in a plastic
bag.
Modbus
Master
