7.1

Accessories

Kneehab ® XP Adhesive Electrodes: Type: 613/ 614/ 615/ 616
Kneehab XP uses adhesive electrodes which have been specifically
®
designed for this unit. Replacement adhesive electrodes are available.
To order replacement electrodes, please contact your local neurotech
supplier. Only accessories specified by BMR Ltd. for use with Kneehab
XP may be used. Using other electrodes may degrade performance
levels. All adhesive electrodes are provided with their own instructions
where necessary, including cleaning, storage and care instructions.
Kneehab ® XP Battery Pack: (3.6V NiMH)
Important:
Under no circumstance should anything other than the correct type of
battery pack (rechargeable, 3.6V NiMH) be used with your unit. These
can be purchased from the neurotech
Disposal of electrodes & battery packs
Used electrodes and battery packs must never be disposed of in a
fire, but in accordance with your country's national laws governing
the disposal of such items. Return the unit and charger to BMR Ltd. or
your local supplier.
Battery Charger (EU - 2504-0303)
Battery Charger (US - 2504-0302)
Charger complies to EN 60950, Input: nominal voltage 100-240V,
frequency 50-60Hz, current 125mA. Do not use any other chargers or
any other power supplies.
18
office.
®
8.0

Technical Information

General Specifications:
Product Type: 411
Classification: Internally powered equipment, Class II charger, Type
BF applied parts.
®
®
Intended Use: Electrical Muscle Stimulator
Waveform: Symmetrical bi-phasic square waveform when measured
into a standard bodyload.
Garment Material:
Outer Fabric: 100% Nylon
Inner Fabric: 70% Polychloroprene, 30% Polyurethane
Binding: 82% Nylon, 18% Elastane
Fastenings: 100% Nylon
Environmental Specifications:
Temperature: 10 to 35°C / 55 to 95°F
Operating Range:
Humidity: 20 to 65% RH
Storage Range: Temperature: 0 to 55°C / 32 to 131°F
Humidity: 10 to 90% RH
Electrical Specifications:
Rated Outputs – Voltage / Currents
Parameter
Output RMSV
Output RMSA
Output Frequency
DC Component: Approx
Positive Pulse Width 100-400 µS
100-400 µS
Negative Pulse Width
Interphase Interval
500 Ω 1K Ω
9.2V 17.4V
18mA 17mA
35 - 50Hz 35 - 50Hz 35 - 50Hz
0 0
100-400 µS 100-400 µS
100-400 µS 100-400 µS
40 µS 40 µS
1.5K Ω
21.0V
14mA
0
40 µS
