4.3 Description of the Unit Display
The following icons appear on the Unit Display at various times throughout the treatment.
Toning intensity from the left-hand side of the garment
Toning intensity from the right-hand side of the garment
Counts down the time left in the current session in minutes and seconds.
Indicates that the session has been paused.
Indicates that the mute function is activated
Intensity button lock is active
This warning symbol indicates a poor contact between the unit and garment or between the electrodes and the skin (see
page 16 for more details).
Shows the battery power remaining.
Shows the programme currently running.
This symbol appears around the edge of the display during each contraction phase.
4.4 Description of the Garment
The inside of the garment has been printed with electrode placement
guides, showing you exactly where to place the 4 electrodes. Two of the
locations will vary depending on your size (A/a and B/b).
For example, the correct position for the large electrode if you are tall is
marked "A", whereas a smaller person would place the same electrode
within the area marked "a".
See page 13 for full details on how to determine your correct electrode
placement.
A/a
B/b
11
