Vue arrière
BATTERY 12V INPUT
3
4
Prise d'antenne FM
Audio In / Audio Out (RCA)
Prise de secteur (230 V~/50 Hz)
AUDIO INPUT
R
Caution:
Back Panel maybe hot Do Not Touch.
Please keep 4-6 inches away from wall
LED Light Switch
OFF
Power Switch
~230V/50Hz
OFF
(CHARGE)
ON
(AC)
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
EXTERNAL POWER SUPPLY
CAUTION
This system can accept extemal power supply DC INPUT voltage
12V
Touse DC INPUT.please switch OFF the AC POWER first,then
connect the external power supply' spositive pole to the RED+
terminal and negative pole to the BLACK-terminal. To operate
the system,,please switch the POWER SOURCE to DCINPUT
1 4 Prise de la batterie (12 V )
2 5 Jeux de lumière LED marche/arrêt
3 6 Marche / Arrêt (charge)
