Mit Arretierstift Gewindekupplung der
Welle aufschrauben
Arretierknopf drücken und Schlauch-
kupplung in die Anschlussbohrung
stecken. Sicher stellen, dass der
Arretierknopf einrastet.
2.1.3 Handstück
1) Arretierknopf
2) Schlauchkupplung
3) Handstück
12
DE
Visser le raccord fileté de l'arbre avec
la tige d'arrêt
Appuyer sur le bouton d'arrêt et
enficher le raccord du tuyau dans
l'ouverture de caccordement. S'as-
surer de l'encliquetage du bouton
d'arrêt.
2.1.3 Pièce manuelle
1) Bouton d'arrêt
2) Raccord de tuyau
3) Partie manuelle
FR
Use locking pin to screw threaded
coupling onto the shaft
Insert locking knob and hose cou-
pling into the connection bore. Make
sure that the locking knob snaps in.
2.1.3 Hand tool
1)
2)
3)
1) Locking knob
2) Hose coupling
3) Hand tool
