Note: the recorded files can also be searched via the included Video Viewer software.
11.

Technical specifications

video format
video compression
video input
video output
video loop out
maximum recording rate (PAL)
adjustable recording speed
image quality setting
hard disk storage
HDD quick cleaning
recording mode
refresh rate
multiplex operation
audio I/O
motion detection area
motion detection sensitivity
pre-alarm recording
backup device
mobile surveillance
Ethernet
network connection
IR remote control
PTZ control
alarm I/O
digital zoom
key lock
video loss detection
camera title
video adjustments
date display format
power source
power consumption
daylight saving
operating temperature
system recovery
dimensions
Use this device with original accessories only. Velleman nv cannot be held responsible in the event of damage or
injury resulting from (incorrect) use of this device. For more info concerning this product and the latest version
of this manual, please visit our website www.velleman.eu. The information in this manual is subject to change
without prior notice.
© COPYRIGHT NOTICE – The copyright to this manual is owned by Velleman nv. All worldwide rights reserved.
No part of this manual may be copied, reproduced, translated or reduced to any electronic medium or otherwise without the
prior written consent of the copyright holder.
V. 01 – 03/06/2014
DVR4H5
PAL
H.264
4 channels, composite video signal 1 Vpp / 75 ohm BNC
HDMI (1080p) & VGA (max. 1920 x 1080 pixels)
-
960H: 960 x 576 pixels @ 75 fps (PAL)
frame: 704 × 576 pixels @ 100 fps (PAL)
-
super best - best - high - normal
built-in SATA type: supports 1 x HDD, supported HDD capacity over 3 TB (HDD not
incl.)
quick clean-up of the "index system" of the recorded files. 1 TB in under 2 seconds
manual / timer / motion / alarm / remote event
100 IPS for PAL
live display, record, playback, backup and network
4 inputs / 1 output
16 × 12 grids per camera for all channels
3 parameters with adjustable sensitivity levels
yes
USB 2.0 flash drive / network (for backup and firmware updates)
EagleEyes software (www.eagleeyescctv.com)
smart phones
CMS
10/100BASE-T, supports remote control and LiveView via Ethernet
supports TCP/IP, PPPoE, DHCP and DDNS function
remote control DVR and PTZ (DVRRC4 incl.)
yes (via RS-485)
4 inputs / 1 output
2 x (live & playback)
yes
yes
up to 6 characters
hue / colour / contrast / brightness
YY/MM/DD, DD/MM/YY, MM/DD/YY, and off
12 VDC
5 W (without hard disk & camera)
yes
10-40 °C
system auto recovery after power reconnected
375 x 61 x 281 mm
10
push status: on iPad, iPod touch, iPhone, Android phone &
tablet
remote login via all smart phone platforms (Apple, Android,
BlackBerry, Nokia Symbian and Windows Mobile)
(Central Management System)
remote surveillance to monitor up to 10 different IP
addresses (Windows & Mac OS)
web browser: Internet Explorer, Firefox, Google Chrome and
Safari via Java, QuickTime or VLC plug-in
