Power Macintosh 6100/60 Users will have to use the Apple HDI-45
cable adapter that comes with the computer in conjunction with the
MultiCable when connecting a MultiSync monitor.
If you have any problems, please refer to the section "Trouble Shooting"
Connection to other Computers or Video cards
If your computer or video card is not compatible with the MultiSync
XP-series colour monitor's preset signals (see timing charts Appendix
B) or has a different pin assignment (see pin assignment table Appendix
A), refer to the steps below to determine if your system is compatible
with the MultiSync XP-series colour monitor or consult your NEC
Dealer.
1. Turn off the power to the monitor and computer.
2. Determine the video connector's pin assignment of your
video card.
3. Determine the output signal timing and level of your video
card.
4. Check the pin assignment and signal timing charts of the
video card and make sure the monitor accepts these pin
assignments and signal timings.
5. Connect the signal cable supplied with your video card to the
monitor.
6. Connect one end of the power cable to the MultiSync
XP-series monitor and the other end to a power outlet.
7. Turn on the monitor and computer.
8. Adjust size and position of the image to your preference.
9. This completes the installation.
If you have any problems, please refer to the chapter "Trouble
Shooting".
