SmartRelais-3-Controller

7 Backup battery

8 Technical specifications for
Housing
Dimensions
Dimensions cir-
cuit board
Material
Colour
Standard pro-
tection rating
Power supply
EN
An empty backup battery may cause the internal clock
to stop in SmartRelays. We therefore recommend
checking the time on the clock at regular intervals. A
backup battery will last for about ten years if the
power supply to the SmartRelay is not interrupted.
This battery should be replaced on a regular basis if
SmartRelay draws on the backup battery at regular
intervals due to frequent power failures.
SREL3
172 × 86 × 33 mm
50 × 50 × 14 mm
ABS plastic, UV-stable
9/118645, same as RAL 9016 (traffic white)
IP20, not tested for outdoor use
7. Backup battery
39 / 148
