4. Housing

4 Housing

4.1 Images and dimensions

4.2 Dimensions of lower housing shell

4.3 Opening the housing lid

32 / 148
(dimensions in mm)
You do not need a tool to open the upper housing
section. Apply slight pressure to the centre of the base
plate on the left- or right-hand side and then you can
remove the upper section.
SmartRelais-3-Controller
EN
