Installation and Operating Instructions
CHAPTER 3
INSTALLATION
Smoke exhaust fan control system – EVS
In case of reshipment (above all, over longer distances; e.g. by sea), it must be checked whether the packaging is sui-
table for the form and route of transport. Damages due to improper transportation, storage or commissioning are not
liable for warranty.
3 .0
Technical data
Type overview EVS
EVS-FUEC
Switching
0-10 V
Power input
Arbitrary
230 V
Nominal voltage
Phases
1~
Current
Alternating
Frequency
50 Hz
Control voltage
24 V
Control fuse
6 A
Y/d start-up time
–
–
Start-up time
Reset spin time
–
Cable entries
8 n
Ambient temperature
0 °C to +40 °C
Protection category
IP54
Housing / control cabinet without connection for centrifugal cooling air fan
Rated output (Type)
4 kW (EVS-W, EVS-D, EVS-FUEC)
4 kW (EVS-SD, EVS-DA)
5 .5 kW (EVS-SD, EVS-DA)
7 .5 kW (EVS-SD, EVS-DA)
11 kW (EVS-SD, EVS-DA)
15 kW (EVS-SD, EVS-DA)
18 .5 kW (EVS-SD, EVS-DA)
22 kW (EVS-SD, EVS-DA)
30 kW (EVS-SD, EVS-DA)
45 kW (EVS-SD, EVS-DA)
55 kW (EVS-SD, EVS-DA)
Housing / control cabinet with connection for centrifugal cooling air fan and integrated air-flow monitors
Rated output (Type)
4 kW (EVS-SD, EVS-DA)
5 .5 kW (EVS-SD, EVS-DA)
7 .5 kW (EVS-SD, EVS-DA)
11 kW (EVS-SD, EVS-DA)
15 kW (EVS-SD, EVS-DA)
18 .5 kW (EVS-SD, EVS-DA)
22 kW (EVS-SD, EVS-DA)
30 kW (EVS-SD, EVS-DA)
45 kW (EVS-SD, EVS-DA)
55 kW (EVS-SD, EVS-DA)
EVS-W
EVS-D
Direct
Direct
up to 4.00 kW
up to 4.00 kW
230 V
400 V
1~
3~
Alternating
Three-phase
50 Hz
50 Hz
24 V
24 V
6 A
6 A
–
–
–
–
–
–
8 n
8 n
0 °C to +40 °C
0 °C to +40 °C
IP54
IP54
Material
Dimensions (H x W x D)
Plastic
320 x 240 x 130
Plastic
400 x 320 x 130
Plastic
400 x 320 x 190
Plastic
400 x 320 x 190
Plastic
400 x 320 x 190
Plastic
480 x 400 x 190
Plastic
480 x 400 x 190
Plastic
480 x 400 x 190
Sheet metal
600 x 600 x 250
Sheet metal
600 x 600 x 250
Sheet metal
800 x 800 x 300
Material
Dimensions (H x W x D)
Plastic
480 x 400 x 130
Plastic
480 x 400 x 190
Plastic
480 x 400 x 190
Plastic
480 x 400 x 190
Plastic
480 x 400 x 190
Sheet metal
600 x 600 x 250
Sheet metal
600 x 600 x 250
Sheet metal
600 x 600 x 250
Sheet metal
600 x 600 x 250
Sheet metal
800 x 800 x 300
3
3
EVS-SD
EVS-DA
Y/d
Y/ YY
up to 55.00 kW
up to 55.00 kW
400 V
400 V
3~
3~
Three-phase
Three-phase
50 Hz
50 Hz
24 V
24 V
6 A
6 A
1.5 - 30 sec.
–
–
1.5 - 30 sec.
–
3.0 - 60 sec.
12 n
12 n
0 °C to +40 °C
0 °C to +40 °C
IP54
IP54
Protection cat . Prot . class
IP54
II
IP54
II
IP54
II
IP54
II
IP54
II
IP54
II
IP54
II
IP54
II
IP54
II
IP54
II
IP54
II
Protection cat . Prot . class
IP54
II
IP54
II
IP54
II
IP54
II
IP54
II
IP54
I
IP54
I
IP54
I
IP54
I
IP54
I
