Bionix OtoClear 7290 Bedienungsanleitung Seite 2

CONTENTS
English . . . . . . . . . . . . . . . . . . . . . . . .
French . . . . . . . . . . . . . . . . . . . . . . . .
German . . . . . . . . . . . . . . . . . . . . . . .
Italian . . . . . . . . . . . . . . . . . . . . . . . . .
Portuguese . . . . . . . . . . . . . . . . . . .
Spanish . . . . . . . . . . . . . . . . . . . . . . .
Reorder Numbers:
#7290 - OtoClear/SprayWash, 20 tips, 1 Ear Basin
#7295 - OtoClear/SprayWash, 5 tips, 1 Ear Basin
3
6
10
14
18
22
Thank you for purchasing the Bionix OtoClear® SprayWash Kit.
The Bionix OtoClear SprayWash Kit provides a simple, yet effective, solution to pa-
tient safety, patient discomfort, and compacted cerumen removal. The key to this
system is the OtoClear ear irrigation tips that are attached to the end of the wand.
OtoClear ear irrigation tips direct water to the ear canal wall at 30 degree angles
avoiding directly impacting the tympanic membrane.
This manual is designed to explain the proper assembly instructions for the entire-
ty of the kit, including bottle assembly, cleaning, and tip placement.
Note: Any other use for the product outside of the intended use stated herein,
Bionix shall not be held liable.
Getting Started:
Unpacking and Verifying Contents:
Before continuing, inspect the package for any damage during shipping. If you
find any damage notify your local distributor.
Next, check to ensure that your OtoClear SprayWash Kit is complete.
Contents include:
• OtoClear SprayWash bottle (with temperature gauge)
• Bottle head with wand attached
• 20 OtoClear Tips (for #7290) or 5 OtoClear Tips (for #7295)
• Ear basin
If any item is missing please contact your distributor.
Intended Use
The Bionix OtoClear SprayWash Kit is intended to be used for Ear Irrigation by a
medical professional.
Before you begin:
Exam the ear canal and tympanic membrane with an otoscope noting the type
and location of any cerumen. Hard or impacted wax may require a cerumenolytic
agent.
WARNING: DO NOT perform irrigation if the tympanic membrane
is perforated or if tympanostomy tubes are present. Discontinue irri-
gation immediately if bleeding, irritation, or other trauma to the ear
canal or tympanic membrane.
Bionix SprayWash Bottle Assembly Instructions:
01. Remove SprayWash Bottle (herein referred to as 'water reservoir') and the
spray head from packaging
02. Grasp the water reservoir firmly.
03. Turn on water source.
04. Fill reservoir with body temperature water. Note: if the temperature of the
water is above 130 O F (54 O C) it will show a blue tail and below 80
will not register on the temperature gauge.
05. After filling, place water reservoir on secure, stable platform.
06. Grasp the head and guide the tube into the opening on the water reservoir
until fully inserted.
07. Point the head and wand in the same direction as the larger end of the reser-
voir base.
O F (27 O C) it
3
