Installation with „Easy Plug cable"
To simplify installing to an OEM or aftermarket ra-
dio the HELIX DSP PRO can also be connected
using the optional Easy Plug Cable (EPC 5.2 - art.-
no. HZ45000) which will supply the processor with
both power and loudspeaker signals of the radio.
No factory wires or plugs need to be cut using this
connection method.
Connection to an OEM radio is detailed below:
right tools disconnect the OEM harness from
nectors of the Easy Plug Cable. You may need
database on the Audiotec Fischer homepage
2. Connect the cable plugs to the car radio.
and the power supply plug (4-pole connector)
to the appropriate HELIX DSP PRO inputs.
4. Please note when connecting the power supply:
The HELIX DSP PRO should not be plugged
this may cause interference. Before connecting
the Easy Plug Cable to the HELIX DSP PRO,
made between the blue and red wires coming
from the ISO connectors of the harness with a
red wire with jack to the corresponding blue or
ness usually has a fuse of max. 20 A.
Attention: The ex factory condition is that the
red wires are connected.
If you're uncertain of assignment ask your
dealer.
20
Note - Cars equipped with MOST bus:
In cars equipped with MOST bus structure it is
original radio connector and insert it into the ISO
adaptor, which has a dedicated recess for this.
-
-
-
