Troubleshooting/Spare Parts - RHEINZINK CLIPFIX Bedienung, Montage, Pflege, Ersatzteile

Error
4 The screw adjustment head
is loose.
5 The guide of the screw adjustment
head sticks.
6 Screws are ejected.
7
8
10
8 The „belt carrier" sticks.
9 The belt guide is loose.
10 The belt is not conveyed properly.
11 Screws can only be tightened using
considerable force.
Spare Parts
6 Bit for RHEINZINK-CLIPFIX auto feed screwdriver
4 RHEINZINK-screw adjustment head

TROUBLESHOOTING/SPARE PARTS

Solution
Tighten the 2.5 mm hexagon screw on the
screw adjustment head.
Grease the guide section of the screw adjust-
ment head.
Replace the bit.
(Item no. 9898009)
Check the depth setting of the bit.
The „belt carrier" sticks (see item 8).
The belt is not conveyed properly (see item 10)
Clean the „belt carrier" regularly using
compressed air and oil it occasionally.
Tighten the 5.00 mm hexagon screws (x2)
on the belt guide.
Set the dial on the belt guide to „4".
If this is stiff or rusted, please use a lubricant
or corrosion remover.
Switch the motor to clockwise rotation!
RHEINZINK-CLIPFIX
Article No.
9898009
9898006
GB
