RHEINZINK-CLIPFIX
OPERATION

1.3.1 Screwing

Correct Insertion Depth
1 Screw head totally screwed in flush with
the fixing clip hole
Incorrect Screwing
2 Protruding screw head
3 Screwing in too deep = strong deformati-
on clip
GB
3
Screwings should only be realized by using the RHEINZINK-CLIPFIX
or the FEIN depth stop. Max. screw size Ø 4,2mm x 55 mm on timber boarding and
18|19
1 2
OSB/veneer plywood sheathing.
The machine is not suitable to be used as a usual screw driller!
How to change the Insertion Depth
The insertion depth can be varied by turning
the adjusting ring on the RHEINZINK-CLIP-
FIX.
Do some test screwing and adjust
■
the adjustment ring according to the
engraving.
If necessary, please repeat this test!
■
Attention!
