Components; Cards; Functions; Handling - Flexlock Visible 2.0 Handbuch

1 Components

1.2 Cards

Programming cards, service cards, Mode cards and user cards can be ordered.

2 Functions

Mode 1 Default setting. Open as default. Can have 1-200 unique users. Programmed user cards/
tags are needed for opening and locking. Flexlock is delivered in Mode 1
if nothing else is requested.
Mode 2 Auto Lock. Locked as default. Can have 1-200 unique users. Programmed user cards/
tags are needed for opening and locking. Locks itself 4 seconds after opening.
Mode 3 Any User. Open as default. For temporary use by one user with any compatible
RFID-card/tag. The exact same card/tag has to be used to open the lock again.
The lock is then ready for a new user.
Mode 4 Any User. Same as Mode 3, with the addition of a time limit. If the user doesn't open
the lock within 12 hours, the lock will then automatically open.
Mode 5 Any User. Same as Mode 3, with the addition of a time limit. If the user doesn't open
the lock within 2 hours, the lock will then automatically open.
Any Timer Special feature. Must be ordered separately via Swedstyle. Same function as Mode 3,
but with a specific time for opening. Time is set throughout hours from 1-166 hours. If the
user doesn't open the lock within this time limit,the lock will then automatically open.
Ready to use is used in Mode 1 or 2. The lock is prepared so that the first user to present a
card is added as a unique user in the lock. This function is added after installation.
Sound on/off Add or remove sound on the lock when it is locked or unlocked.

3 Handling

More instructions are available at www.flexlock.se
English 5
