9 Technical specification

Flexlock is CE marked and meets the requirements
Size
Door thickness (max)
Hole pattern
Lock cams
Weight (including battery)
Temperature, surrounding
Humidity
IP-code
Number of users
Battery
Battery lifespan
RFID
Compatible with
Reading distance
Lock standard
Electrical safety
EMC and EMR radio test
* Requires upgrading of locks when future feature is implemented.
101x52x25 mm without knob (34 knob included)
24 mm
Ø22x18 mm, Ø19x16 mm
See standard lock cams.
Options can be optimized to specific cabinets
225 g
+17° C to +30° C
20% to 75% relative humidity, non condensing
IP 52
max 200 users
If your Flexlock Visible should work properly, the battery
must be a Flexlock branded battery available through Swedstyle
or your Flexlock dealer.
3 years or 30 000 openings
13,56 MHz, ISO/IEC 14443 A &B, ISO/IEC 180092, ISO/IEC 15693
13,56 MHz: Mifare Classic 1k, Mifare Classic 4k,
Mifare DESFire EV1 & EV2, ISO 14443A, Legic Advant 15693,
Mifare Plus, Mini, Ultra Light HID iClass 2k, iClass 4k, iClass SE 2k,
32k, prepared for NFC*.
0-15 mm with Flexlock-cards, <5 mm with tag
SS-EN 16014:2011, Dimensioned for DIN 4547 Class B
IEC/EN/UL 62368, CSA 22.2
ETSI 300 330-1/-2 and 301 489-1/-3, FCC Part 15B, ICES-003
