RAS addressing
The address of the reader for BUS operations is set to the
default address RAS 16. Using a configuration card or
accessing its on-line Menu system when connected to the
RS485 BUS can change this. See the Programming Guide,
Reader Address, for further details.
Tamper
The reader is provided with a Tamper facility. When connected
to the BUS, Tamper data is transmitted to the Advisor Master
with system data. An external Open Collector output (violet
wire) can be configured as a Tamper control for both online
and offline operation.
Reader wiring
Red Positive 9 to 14 VDC supply
Black 0 Volts DC supply ground
Green D0/D− RS485 Data − Wiegand Data 0
Clock
Absolute maximum, 12 V @ 10 mA
White D1/D+ RS485 Data + Wiegand Data 1
Data
Absolute maximum, 12 V @ 10 mA
Brown LED 1 Offline LED control configured to "Two
Wire Control" will control the red LED only
Wire grounded: Red LED on
Wire open: Red LED off
Wire at +5 V to +12 V: Red LED off or,
offline LED control configured to "One
Wire Control" will control both the red and
blue LED's
Wire grounded: Blue LED on
Wire open circuit: Both LED's off
Wire at + 5 V to 12 V: Red LED on
Absolute maximum, 14 V
Yellow LED 2 Configurable to control the blue LED when
offline
Wire grounded: Blue LED on
Wire open: Blue LED off
Wire at +5 V to +12 V: Blue LED off
Request to exit input when online to
Advisor Master
This input may be connected to a simple
push button connected to Ground with
RTE Only selected on the option card or in
Menu 10 (See Programming Guide for
more details).
Blue Buzzer Offline Buzzer control.
Wire open or +5 V to +12 V: Buzzer off
Wire grounded: Buzzer sounding
Absolute maximum, 14 V
Violet Open Configurable as: Door relay, −Tamper
Collector output, Credit controlled Pulsed, Timed or
Latched output
Note:
must not be used to directly energise high
current door openers.
Absolute maximum, 14 V @ 25 mA
2 / 16
This is a low current output and

Specifications

Number of card combinations
Supply voltage
Current consumption
Dimensions of housing
Operating temperature
Relative humidity
Protection class

Regulatory information

Manufacturer UTC Fire & Security Americas Corporation, Inc.
1275 Red Fox Rd., Arden Hills, MN 55112-6943, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Certification
1999/5/EC (R&TTE directive): Hereby, UTC Fire &
Security declares that this device is in compliance with
the essential requirements and other relevant
provisions of Directive 1999/5/EC.
2002/96/EC (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more
information see: www.recyclethis.info.
Contact information
www.utcfireandsecurity.com or www.interlogix.com
For customer support, see www.interlogix.com/customer-
support.

DA: Installations vejledning

Introduktion
ATS1190/1192 Smart Card Læser er en multifunktions-,
berøringsfri kortlæser beregnet for alle placeringer hvor en
kort læseafstand vil dække det ønskede behov. Læseren kan
tilsluttes direkte til en Advisor Master centralenhed (se figur 2).
Læseren konfigureres via databussen eller via et
Konfigurationskort som programmert fra Titan PC-software og
Smart Card Programmerer (ATS1621/22) eller med ATS1481
Programmeringskort.
Læseren opererer fra 9 til 14 VDC. Den har et strømforbrug på
mindre en 25 mA i hviletilstand og mindre en 80 mA under
læsing af kort. ATS1190 leveres standard med et hvid
aftageligt dæksel. Løse dæksler kan tilbydes i yderligere 4
forskillige farver.
ATS1192 er en mere robust udgave designet for standard
dørkarme.
Både ATS1190 og ATS1192 er vandtætte.
P/N MAINST-ATS1190 • REV B • ISS 25JAN12
12
28x10 — 48 bit
9 to 14 V
25 mA
80 mA max.
ATS1190: 36 x 110 x 20 mm
ATS1192: 42 x 150 x 16 mm
−35 to +66°C
93%, noncondencing
IP54
