SERVICE
In addition to the already described service work should always try to keep your vehicle in order to prevent wear. If there
is dirt in moving parts, this can affect the performance of the model signifi cantly. Remove dirt or dust with compressed
air, a soft brush and / or with a toothbrush. If possible, try using no solvents, as this can move the dirt in normally inac-
cessible places and thus cause additional wear. We recommend the following simple procedures:
Remove dirt and dust as far as possible with the methods described above.
Check the car for worn, broken or gripping parts and repair them if necessary.
Check regularly the fi xed seating all screws and tighten them if necessary.
SERVICE AND REPAIR, SPARE PARTS
For the Radicator 3.0 all parts are available as spare parts. So if a part is defective or worn, you can identify these parts
with the Exploded view, buy these parts and fi x the car yourself with the help of the assembly instruction (pages 33 -
40).
In problem cases, or for questions and repairs, please contact the Service department in your country (see
warranty card on page 42) or:
GRAUPNER-Service, Henriettenstrasse 94-96, D-73230 Kirchheim/Teck,
Tel. +49/1805/472876
SPARE PARTS: at your local hobby shop or online at GM-Racing http://www.gm-racing.de/en under order.-nr.: 90157.
RTR, 90158.RTR or 90159.RTR.
SPECIFICATIONS RADICATOR 3.0
Lenght:
Width:
Height:
Wheelbase:
Weight (battery ex-
cluded):
Ground clearence:
Wheel diameter:
Gear ratio:
Motor:
Radio system:
Specifi cations ESC:
Number of cells NiMH / LiPo
Constant current forward
Constant current reverse
Dimensions
GM-Racing Radicator 3.0 Buggy - Truggy - Monster Truck
Buggy
Truggy
405 mm
420 mm
245 mm
320 mm
155 mm
165 mm
275 mm
275 mm
1300 g
1650 g
18 mm
30 mm
88 mm
105 mm
1:8.8 (23 T)
1:8.8 (23 T)
1:9.6 (21 T)
RC 540
RC 550
GM-Racing
GM-Racing
XS-4i 2.4 GHz
XS-4i 2.4 GHz
4-6 / 2 (max. 7.4 V DC)
30 A (45 A ~ 10 sec.)
20 A (30 A ~ 10 sec.)
ca. 45x35x15 mm (w/o wiring)
Monster Truck
400 mm
320 mm
200 mm
275 mm
1700 g
40 mm
125 mm
1:8.8 (23 T)
1:9.6 (21 T)
RC 550
GM-Racing
XS-4i 2.4 GHz
16
