7.1. Installation instruction for Group 0+/I(0-18kg), Rearward
facing , ISOFIX + Support Leg + harness.
Turn on the power switch. (There is electro-
nic system for last ROM PLUS version, none for
ROME version)
Unfold support leg until it locks in place. Press the
ISOFIX release button to slide the ISOFIX connec-
tors to the end.(There is lights on at the back of seat
for last ROME PLUS version, No function for ROME
version)
Caution:
-Please only move to next step when ISOFIX has
been slid to the end with appearing the red marks.
Push the ISOFIX connec-
tors directly into the anchora-
ges until you hear an audible
sound "click" Push the ISOFIX
connectors directly into the
anchorages until you hear an
audible sound "click"

INSTALLATION IN THE VEHICLE

7.1.1. 3
7.1.1. 1
7.1.1. 2
clic k
