Wiseup W7000 Bedienungsanleitung Seite 4

3.5.2. Press and hold the Mode Button for 2 seconds to turn on the IR LEDs. The red
indicator light will flash 3 times and turn off, then the IR LEDs will glow solid red.
3.5.3. Press the Mode Button once to turn off the IR LEDs. The blue indicator light will
flash 3 times and turn off.
[Note]:
IR Distance: 2m
IV. Video/Image/Audio File Uploads
4.1. Power off the camera and unscrew the knob cover to reveal the mini USB port.
4.2. Connect the camera to a proper PC computer USB port using the USB cable provided.
4.3. The camera will be recognized as a removable disk drive.
4.4. All the files can be accessed in the drive.
V. Setting Time/Date Stamp
5.1. Power off the camera and unscrew the knob cover to reveal the mini USB port.
5.2. Connect the camera to a proper PC computer USB port using the USB cable provided.
5.3. The camera will be recognized as a removable disk drive.
5.4. Click on the drive in the root directory and inside the root directory, open the file
named "time.txt".
5.5. Write the current date and time in the "time.txt" file with the correct format:
YYYY-MM-DD HH:MM:SS Y (For example: 2017-04-12 14:24:32 Y). Save this file. If you
don't need the time and date stamp on the video footage, change "Y" into "N" in the "time.txt"
file. (For example: 2017-04-12 14:24:32 N)
5.6. Restart the camera and the system will upgrade the program automatically.
VI. Charging
6.1. Power off the camera and unscrew the knob cover to reveal the mini USB port.
6.2. Connect the camera to an outlet AC power supply using the DC5V power adapter
and the USB cable provided.
6.3. The red indicator light will stay illuminated while the blue indicator light will flash
slowly during the charging process.
6.4. It will take 2 hours to obtain a full charge.
6.5. Both blue and red indicator lights will remain solid when the camera is fully charged.
