PRePaRatiOn

intended use
• the intended use of this HiFi system includes the playback of audio- and MP3/WMa-cDs, radio, USB flash
devices, memory cards (SD/MMc) with MP3/WMa files and external sources. the appliance is only intended
for domestic and private use. never use the appliance outdoors!

unpacking and checking

• Remove all packaging and check the appliance for transport damage.
• Do not use the appliance if it is damaged in any way. Bring it back to the dealer immediately.
• check if the delivery is complete.
• If possible, keep the packing until the end of the warranty.
• Ensure that air is free to circulate through the product. Your appliance has ventilation holes, which should
never be obstructed. Keep a distance of 10cm at least.
• Open the cD compartment (28) and remove the transport protection.

Remote control

• Remove the plastic tab from the battery compartment (47) at the rear of the remote control. Pull it gently.
• Replace a used battery.
• Open the battery compartment and insert one battery of the type
cR 2032 (Fig.1).
• Pay attention to the correct polarity (+/-) in accordance with the
markings.
• close the battery compartment. Make sure that the cover is
locked in place.
• also read the safety instructions for handling batteries (see
chapter Important safety instructions).
loudspeaker
• connect the grey and black cables of the left and right loudspeaker with the according grey and black
loudspeaker terminals (23) on the back side of the appliance.
• the loudspeakers have a loudspeaker cover (31). Place the cover on the loudspeaker or use the
loudspeakers without covers.
antenna
• the appliance has two antennas – a wire aerial (21) for FM and a loop antenna (27) for aM. Unroll the FM
wire aerial and stretch it into the direction with the best reception.
• Do not unroll the MW loop antenna. Bend the plastic part in the middle and attach it at the bottom side of
the antenna. connect the plug with the designated aM ant. jack (22) on the appliance and position the
antenna.
