Correct Disposal Of This Product - Andis SMC Typ C Anleitung

If upon cleaning your blades you find that the blades will still not cut, there may be a
few fine pieces of hair trapped between the upper and lower blade. If this happens,
you will need to snap the blade off the clipper. Proceed to slide the upper blade to
one side, without loosening the tension spring or moving the upper blade
completely out from under the tension spring (See Figure L for position of blade).
Wipe the surface between the blades clean with a dry cloth, then place a drop of
clipper oil where the upper and lower blades meet and also in the guide slot of the
tension spring (Figure L). Now slide the upper blade to the opposite side of the lower
blade and repeat this process. After completing this procedure, slide the upper
blade, centering it over the lower blade. Handle or store your Andis clipper with the
blades down so excess oil will not run into the clipper case.
CHANGING THE BLADE DRIVE ASSEMBLY
If your clipper blades no longer cut properly (be sure to try more than one blade,
since the blade currently being used may be dull), it could be that your blade drive
assembly needs replacement.
TO CHANGE THE BLADE DRIVE ASSEMBLY:
1. Remove blade set (Figure H).
2. Remove drive cap (Figure M).
3. Remove blade drive mounting screws (Figure N).
4. NOTE: Before removing blade drive assembly, note the way it is positioned (this will
help you in reassembly). Remove blade drive assembly (Figure O).
5. Drive bearing should be at its lowest position, if not, move it with your finger to
lowest position (Figures P & Q).
6. Put on new drive assembly, align screw holes and press down (Figure O).
7. Reassemble blade drive by mounting screws (Figure N).
8. Replace drive cap (Figure M).
9. Replace blade (Figure J).
FACTORY REPAIR SERVICE
When the blades of your Andis clipper become dull after repeated use, it is advised
to purchase a new set of blades available through your Andis supplier or through an
Andis authorized service station.

CORRECT DISPOSAL OF THIS PRODUCT

This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return your
used device, please use the return and collection systems or contact the retailer where
the product was purchased. They can take this product for environmental safe recycling.
CAUTION: Never handle your Andis clipper while you are operating a water faucet
and never hold your clipper under a water faucet or in water. There is danger of
electrical shock and damage to your clipper. ANDIS COMPANY will not be
responsible in case of injury due to this carelessness.
7
