Quick Removal Of Interphone From Helmet; Basic Operations; Making A Call - Cellular Line INTERPHONE Bedienungsanleitungen

INTERPHONE
GB
4. Connect the headset with microphone connector (B) to the socket
(5) on the Bluetooth module. The connector can only be inserted in
one position (photos S/T).
5. Any extra wire should be placed inside the helmet (photos U/V).
The INTERPHONE is now installed and ready for use.

Quick removal of interphone from helmet

To remove the Bluetooth module, press the blocking handle against
the helmet shell (photo O). Keep it pressed down and slide the
Bluetooth module upwards.

Basic operations

IMPORTANT: before using the following functions, the INTERPHONE
must be paired with the phone with which it is to be used (see the
paragraph "Pairing with a Bluetooth phone")
VOLUME CONTROL
Initial volume adjustment must be done with the motorbike on, but not
moving. Press volume button 3 to raise the volume or 4 to lower it.
When the motorbike is moving, the listening volume is automatically
adjusted. It increases with speed (and therefore noise levels) automat-
ically and decreases at lower speeds.
AUDIO TRANSFER
During a call, the audio can be transferred from INTERPHONE to a
mobile phone or vice versa.
From INTERPHONE to Mobile Phone -
Press and hold down the multifunctional button (1) for 2 seconds.
When you hear the second confirmation sound, release the button and
the audio will be transferred to the mobile phone.
From Mobile Phone to INTERPHONE -
Press the multifunctional button (1) for 1 second. You will hear a con-
firmation sound and the audio will be transferred to the headset.

MAKING A CALL

Type in the number using the phone, the audio will automatically be
sent to the Bluetooth headset.
N.B.: Some phones such as Siemens S55 do not send the audio auto-
matically to the Bluetooth device. In this case, press the multifunction-
al button (1) to transfer the audio to the device.
