AME 23, AME 23 SU, AME 33
MAINTENANCE
FREE
4 – 6 mm × 1 mm 32 mm
❷
①
1× 32 mm
❸
Wiring for modulating mode
Proportional 3 point/RL
SN
0 V
SP
24 VAC
0(2)-10 V
Y
0(4)-20 mA
1
0 V
3
X
0(2)-10 V
Wiring for 3-point floating mode
Controller with relay output
Proportional 3 point/RL
SN 0 V
SP
24 VAC
1
24 VAC
3
X
0(2)-10 VDC
2 | © Danfoss | 2017.01
5-95 % RH
no condensing
T 10
②
①
②
Max 25 Nm
Neutral
Power supply
Input
Input
Output
Neutral
Power supply
Input
Output
❶
5 mm
4×
or
③
③
④
AME 23,
AME 33
OPEN
1× 5 mm
Wiring for 3-point floating mode
Controller with triacs output
Proportional 3 point/RL
SN
24 VAC Neutral
SP
0 V Power supply
1
24 VAC Input
3
X
0(2)-10 VDC Output
CLOSE
AME 23 SU
