1.3 Pin Header Easy Installation Guide
ASRock motherboards are equipped with pin headers with obvious colors
that assist you to recognize the crucial headers. Please refer to the illustra-
tion of the onboard headers' pin defintion below. If you need more informa-
tion about the usage of these headers, please refer to "Onboard Headers
and Connectors" and "Jumper Setup" for details.
USB 2.0 Header
HDMI_SPDIF
Header
10
USB 3.0 Header
F r o n t P a n e l
Audio Header
ASRock H61TM-ITX Motherboard
Power LED Header
System Panel Header
USB 2.0 Header
