OSRAM DALIeco BT RTC control Sicherheits- Und Montagehinweise Seite 2

DALIeco BT RTC control
DALI control unit with Bluetooth Low Energy interface
V
AC
P
t
a
2)
DALI control interface
4)
Push button interface
6)
Wireless interface
8)
Type of protection
9)
Max. DALI load
11)
Allowed leads diameter
Time switch with energy storage
Dimensions / Abmessungen
15)
Mounting hint / Montagehinweis
Wiring scheme / Anschluss-Schema
24)
OSRAM GmbH
Berliner Allee 65
86153 Augsburg
Germany
www.osram.com
220-240 V; 50/60 Hz
0.3 - 3W
-20...+60 °C
DA + / DA - / 15 V / max. 300m total wire length
DC
max. total wire length PB1: 50m; PB2: 5m (see wiring scheme)
Bluetooth 4.0 / Connectivity range
®
IP20
• 32 ECG + 4 OSRAM DALI Sensors or OSRAM DALI Push button couplers
• 96 mA
0.5 - 1.5 mm 2
12)
72h buffer in case of mains power failure (charging time min. 24h mains operation)
14)
18)
16) 17)
19)
20)
21)
23)
25)
3)
5)
7)
: ≤ 15 m
APP for configuration and control /
APP für Konfiguration und Steuerung
