Instructions for installation and use

3.3. Changes for the right floor plan installation

Exchanging the electrical element with the A/A wall element
with Multiclip (Page 31)
Remove the external tongue element from the A/A wall element with Multiclip
and insert it in the electrical element.
A/A wall element with Multiclip
Electrical element
*
*
*
*
Multiclips
External tongue element
Right floor plan
p. 31/32
*
EN
*
*
