NATURE POOL
TOP 132-120
Nos reservamos el derecho de cambiar total o parcialmente las características de nuestros artículos o contenido de este documento sin previo aviso.
Nous nous réservons le droit de modifier totalement oru en partie les caracteristiques de nos articles ou le contenu de ce document san pré avis.
Wir behalten uns das recht vor die eigenschaften unserer produkte oder den inhalt diese prospektes teilweise oder wollstanding, ohne vorherige benachichtigung su andern.
Ci riservamo il diritto di cambiare totalemente o parzialmente le caratteristiche tecniche dei nostri prodotti ed il contenuto di questo documento senza nessum preavviso.
Wij behouden ons het recht voor geheel of gedeeltelijk de kenmerken van onze artikelen of de inhouk van deze handleiding zonder voorafgaand bericht te wijzigen.
Reservamo-nos no dereito de alterar, total ou parcialmente as caracteristicas os nossos artigos ou o conteúdo deste documento sem aviso prévio.
HIMNP/06
NATURE POOL
GB
BEFORE STARTING ASSEMBLY, READ THE INSTRUCTIONS BELOW CAREFULLY.
E
ANTES DE PROCEDER AL MONTAJE, LEA DETENIDAMENTE LAS SIGUIENTES INSTRUCCIONES.
F
AVANT DE PROCÉDER AU MONTAGE DE LA PISCINE, LIRE ATTENTIVEMENT LES INSTRUCTIONS SUIVANTES.
D
VOR DER MONTAGE BITTE DIE SICHERHEITSHINWEISE BEACHTEN.
I
PRIMA DI PROCEDERE AL MONTAGGIO LEGGERE ATTENTAMENTE LE SEGUENTI ISTRUZIONI.
NL
LEES EERST AANDACHTIG DE VOLGENDE INSTRUCTIES DOOR, VOORDAT U MET DE MONTAGE BEGINT.
P
ANTES DA MONTAGEM, LER COM ATENÇÃO AS INSTRUÇÕES DADAS A SEGUIR.
We reserve to change all of part of the articles or contents of this document, without prior notice.
®
®
®
Werbung
Verwandte Anleitungen für GRE NATURE POOL TOP 132-120
Inhaltszusammenfassung für GRE NATURE POOL TOP 132-120
- Seite 1 LEES EERST AANDACHTIG DE VOLGENDE INSTRUCTIES DOOR, VOORDAT U MET DE MONTAGE BEGINT. ANTES DA MONTAGEM, LER COM ATENÇÃO AS INSTRUÇÕES DADAS A SEGUIR. FABRICADO POR: MANUFACTURAS GRE, S.A. ARITZ BIDEA, 57 TROBIKA AUZOTEGIA APARTADO 69 48100 MUNGUIA (VIZCAYA) ESPAÑA Nº...
- Seite 2 I N S TA L A Ç Ã O DELIVERY FOR ATTENTION OF THE CONSUMER - SERVICIO ATENCION AL CONSUMIDOR - LIVRAISON A L’ATTENTION DU CONSOMMATEUR WATERMAN GMBH NEOGARD AG Kundendiest POOL MANUFACTURAS GRE, S.A. POOL SERVICE Nürtiger Str. 48 D-73257 Köngen Oberkulmerstrasse Aritz bidea nº...
- Seite 3 SAFETY PRECAUTIONS I N S T R U C T I O N S CONSEJOS DE SEGURIDAD PA R T E CONSEILS DE SECURITE SICHERHEITSHINWEIS CONSIGLI DI SICUREZZA RAADGEVINGEN VOOR DE VEILIGHEID CONSELHOS DE SEGURANÇA ® DANGER "INUNDATION" ®...
- Seite 4 TELEFONO CONSULTAS: Tel.: (34) 946 741 844 Tel.: 00 (33) 4 92 28 32 78 Fax.: 00 (33) 4 92 28 03 33 Suisse, numéro verde: 0 800/563 820 e-mail: gre@gre.es web: www.gre.es Fax: (34) 946 740 321 e-mail: gre@gre.es web: www.gre.es e-mail: samuel@gre.es web: www.gre.es...
- Seite 5 Tel.: (34) 946 741 844 Belgïe: Tel.: 0800 10 211 Suizzera, numero verde: 0 800/563 820 e-mail: pool@neogard.ch Fax: (34) 946 741 708 e-mail: gre@gre.es web: www.gre.es e-mail: gre@gre.es web: www.gre.es e-mail: gre@gre.es web: www.gre.es e-mail: info@waterman-pool.com web: www.gre.es ®...
- Seite 6 P R E P A R A T I O N O F T H E S I T E I N S T R U C T I O N S P R E P A R A C I O N D E L T E R R E N O PA R T E P R È...
- Seite 7 3,5 m Installation place: Our pols are designed to be erected above ground an for an outdoor family use. The ground has to be firm, flat and perfectly horizontal. Remenber: 1000 lts of water = 1 m = 1000 Kgs. Advices to chose the best location for your pool: •...
- Seite 8 (not included) Tool necessary (no incluida) Herramienta necesaria F L O U R (n'est pas compris) Outil nécessaire H A R IN A (nicht eingeschlossen) Erforderliches werkzeug FA R IN E (non compreso) Utensile necessario M E H L (niet inbegrepen). Benodigd gereedschap (não éstá...
- Seite 9 Levelling: When levelling the ground, always remove material from the top of the slope rather than filling in the bottom: this will ensure greater ground stability and firmness. Always remove all grass, roots, stones, etc. Levelling is extremely important: devoting the necessary time and effort to ensuring that your pool sits properly on the ground will avoid problems later.
- Seite 10 T P R ó M P R Finishing: On the cleaned and levelled ground, spread a light coat of sieved sand (max. 1cm). Water and compact it (with a garden roller). Check that is well levelled. Do not use the sand to level the ground. The finishing has to be perfect. We advise to put a ground cover (TPR) or a thick one (MPR) above the compact ground.
- Seite 11 I N S T R U C T I O N S COMPONENTS Draw and clasify all components included before assembly. It's time to assemble the ladder and the pump, follow the respective instructions.Your swimming pool is supplied on 2 pallets. Pallet No. 1: Metal-sided swimming pool: Liner + wallplate + PVC section pieces + filtering system + ladder (inox) + cover + woodstainer kit + wood screws + metal trims (TMC-ES-EVR).
- Seite 12 COMPONENTS COMPONENTES ELEMENTS BESTANDTEILE COMPONENTI ONDERDELEN COMPONENTES Ø Ø Ø Ø PALET PALET Nº 1 Nº 2 LINER LINER PIPC TPVC PIPC T P V C TINTE PLYME=PLYMI x 2,5 lts x 3,8 lts x 2,5 lts x 2,5 lts T F L T F M T F C...
- Seite 13 C O M P O N E N T S C O M P O N E N T E S E L E M E N T S B E S TA N D T E I L E C O M P O N E N T I O N D E R D E L E N C O M P O N E N T E S Ref.
- Seite 14 WOODEN LADDER COMPONENTS For the stainless steel ladder, see the instructions inside the package. NOTE: references: NP451 - NP351 do not contain the component with ref.: WOODEN LADDER, AR1175 and AR1174. COMPONENTES ESCALERA DE MADERA Para la escalera de acero inoxidable vea las instrucciones en su embalaje. NOTA: las refs.: NP451 - NP351 no contienen el componente ref.: ESCALERA DE MADERA,AR1175 y AR1174.
-
