SPECIFICATIONS
The M-3295 fuel pump is designed to safely transfer diesel
fuel. The pump is designed for permanent mounting on vented
storage tanks, either in-ground or above-ground.
Performance
Pump Rate: Up to 113.5 LPM @ 60 Hz (95 LPM @ 50 Hz)
Duty Cycle: 30 minutes ON, 30 minutes OFF
Dry Prime: 15 ft. (4.6 m) maximum
Discharge Lift: 10 ft. (3 m) maximum
Operating Temperature
-20° F to +125° F (-29° C to +52° C)
Operating Pressure
25 PSI
Electrical
Input: Factory set at 230 VAC, 60/50 Hz
Conduit: 1/2 inch -14
Current Draw: 4.9 amps (on 60 Hz) and 5.7 amps
(on 50 Hz) at full load on 230 VAC
Motor: 3/4 HP, 1725/1425 RPM induction
type with internal thermal protection
Mechanical Connections
Bung: 2 inch Male BSPT
Inlet: 1-1/4 inch Female BSPP
Outlet: 1 inch Female BSPP
Accessories
Hose: 1 in. x 12 ft. (3.7 m) Buna-N statically
grounded
Nozzle: 1 in. manual leaded spout or 1 in. auto-
matic diesel
Security: Nozzle can be padlocked
Ship Weight: 75 pounds (34 kg)
SERVICE
In order to preserve the UL Listing of motor, return the entire
pump to the factory for motor repair or replacement. If the
motor is removed from the pump or serviced outside the
factory, the UL nameplate on the pump must be removed or
defaced to indicate loss of UL Listing.
This product has a 2 year limited warranty. For warranty con-
sideration, parts, or other service information, please contact
your local distributor. If you need further assistance, contact
the GPI Customer Service Department in Wichita, Kansas,
during normal business hours.
Tel: 316-686-7361
Fax: 316-686-6746
To obtain prompt, efficient service, always be prepared with
the following information:
1. The model number of your pump.
2. The manufacturing date code of your pump.
For the M-3295 series, the date code is located on the motor
nameplate.
For warranty work, always be prepared with your original sales
slip or other evidence of purchase date.
Please contact GPI before returning any pump. It may be
possible to diagnose the trouble and find a solution with a
telephone call. GPI can also inform you of any special require-
ments you will need to follow for shipping.
CAUTION
Do not return the pump without authority from the Cus-
tomer Service Department. Due to strict government
regulations, GPI cannot accept pumps unless they have
been drained and cleaned.
