ILLUSTRATED PARTS DRAWING
33
22
2
31
19
11
9
Item
No. Part No. Description
2 121010-11 Shaft Key (or Kit
3 121013-1 Check Valve Assembly ..........................1
6 901001-90 O-Ring (or Kit
7 901002-50 O-Ring (or Kit
8 901002-89 O-Ring (or Kit
9 904001-37 Hex Head Screw 5/16 - 18 x 3/4 ...........8
11 904006-38 Hex Head Screw 3/8 - 16 x 1 ................2
12 904006-54 Socket Head Screw 3/8 - 16 x 1 ...........3
13 904006-57 Spacer Washer ......................................2
14 121019-1 Spring ....................................................1
15 133026-1 Slinger Washer ......................................1
16 133027-1 Spacer Washer (or Kit
17 13312401 Nozzle Cover .........................................1
18 133031-4 Base ......................................................1
19 133032-1 Coverplate .............................................1
20 133033-1 Base End Plate ......................................1
Kits and Accessories
A
133502-1 Vane Kit
B
133503-1 Shaft Seal Kit
C 133504-1 Seal Kit
133534-01 Switch Kit, M-3130/M-3295
✽ To retain Underwriters Laboratory (UL) Listing, any motor repair or service must be completed by a repair shop authorized by UL or
returned to the factory. If the motor is removed from the pump, serviced, or repaired by an unauthorized repair center, the pump should
indicate loss of UL Listing by removal or defacing of appropriate labels.
4
15
21
12
35
16
34
23
8
3
14
6
20
Req'd.
A
)..............................1
C
) ..................................1
C
) ..................................1
C ) ..................................1
B
) .....................1
17
24
39
18
32
30
7
27
9
38
No.
Item
No. Part No.
21 133039-1
22 133041-1
23 133042-1
24 133043-1
26 133058-1
133049-1
27 133059-1
30 133064-1
31 901003-15
32 904004-89
33 904006-33
34 904006-49
35 906006-53
36 906005-2
37 110155-28
38 121036-1
39 133505-01
26
13
36
37
Description
Housing .................................................1
Rotor ......................................................1
A
Vanes (or Kit ) ...................................8
3/4 HP Motor, 115/230 volt
Switch Lever for Manual Nozzle ............1
Switch Lever for Automatic Nozzle .......1
Poppet Plug ...........................................1
Poppet Spring .......................................1
C
O-Ring (or Kit ) ..................................1
Spring Pin ..............................................1
B
Retaining Ring (or Kit
Hex Head Screw 3/8 - 16 x 3-3/4 .........1
Shaft Seal (or Kit B ) .............................1
1" BSPP Automatic Nozzle ...................1
1" BSPP Manual Nozzle ........................1
Hose Assembly......................................1
Poppet Assembly Kit .............................1
No.
Req'd.
...............1
✽
) ......................4
