SR100
Control unit
Type
Power supply
N° motors
Motor power supply
Flashing light
Accessories power supply
Functioning time
Pause time
Radio receiver
Operating temperature
TECHNICAL SPECIFICATIONS / FUNCTIONS
• Red warning led of n.c. contacts (photo).
• Green warning leds of n.o. contacts (start, general_open, general_close).
• Green warning leds of phases during time learning procedure.
• Yellow warning led for emergences
• Red warning led of radio codes learning
• Key LEARN to memorize radio codes
• Key START on board.
• Possibility of using the SAF input as limit switch.
• Time self- learning.

INSTALLATION WARNINGS

• Before proceeding with the installation, fit a magnetothermal or differential switch with a maximum capacity of
10A upstream of the system. The switch must guarantee omnipolar separation of the contacts, with an opening
distance of at least 3 mm.
• To prevent possible interference, differentiate and always keep the power cables (minimum cross-section
1,5mm²) separate from the signal cables (minimum cross-section 0,5mm²).
• Make the connections referring to the following tables and to the attached screen-print. Be extremely careful to
connect in series all the devices that must be connected to the same N.C. (normally closed) input, and in
parallel all the devices that share the same N.O. (normally open) input. Incorrect installation or improper use of
the product may compromise system safety.
• Keep all the materials contained in the packaging away from children, since they pose a potential risk.
• The manufacturer declines all responsibility for improper functioning of the automated device if the original
components and accessories suitable for the specific automation are not used.
• At the end of the installation, always check carefully the proper functioning of the system and the devices used.
• This instruction manual addresses people qualified for the installation of "live equipment". Therefore, good
technical knowledge and professional practice in compliance with the regulations in force are required.
• Maintenance must be carried out by qualified personnel.
• Before carrying out any cleaning or maintenance operation, disconnect the control unit from the mains.
• This control unit may only be used for the purpose for which it was designed.
• Use of the product for purposes different from the intended use has not been tested by the manufacturer,
therefore any work is carried out on full responsibility of the installer.
SR100 / AS05190
Electronic control unit for the automation
of a shutter motor
230Vac monophase 50/60 Hz
1
230 Vac
230Vac 25W max
24Vdc 1,2W max
125 s max
125 s max
433,92 Mhz on board
-20°C +60°C
9
