1. GENERAL CHARACTERISTICS

Application range
Max. cutting diameter
Dimensions (ref. to Fig. 6)
Weight with battery
Motor
Operating temperature
Recommended oil
Operating speed
Safety
Rechargeable battery
Type
Weight
(1)
Acoustic noise
L
pA
L
pCPeak
L
WA
(2)
Vibration
Battery charger
Input V / Hz
(1)
Directive 2006/42/EC, annexe 1, point 1.7.4.2 letter u
L = weighted continuous acoustic pressure level equivalent.
pA
L = maximum value of the weighted acoustic displacement pressure at the work place.
pCPeak
L = acoustic power level emitted by the machine.
WA
(2)
Directive 2006/42/EC, annexe 1, point 2.2.1.1
Weighted root mean square in frequency of the acceleration the upper limbs are exposed to for each biodynamic
reference axis. Tests carried out in compliance with the indications contained in EN ISO 5349-1/2 and UNI EN 28662-1
Standards, and under operating conditions much more severe than those normally found.
5
mm (inches)
mm (inches)
kg (lbs)
V
°C (°F)
twin speed operation and automatic switching from a rapid
advancing speed of the ram to a slower, more powerful speed
V / Ah / Wh
kg (lbs)
dB (A)
dB (C)
dB (A)
2
m/s
B-TC500ND-SC B-TC500ND-SCE B-TC500ND-SCT B-TC500ND-SCA
type
ASC30-36-EU
W
suitable for cutting Copper, Aluminium
or telephone cables
52,5 (2")
526 x 152 x 81 (20.7 x 6 x 3.2)
3,9 (8.6)
-15 to +50 (+5 to +122)
TOTAL DIEKAN 1640 or equivalents
maximum pressure valve
18 / 2.0 / 36
CB1820L (Li-Ion)
0,4 (0.9)
a
hv
ASC30-36
ASC30-36-UK
-AUS/NZ
220-240 / 50-60
85
18
67,7
89,2
74,2
0,724
ASC30-36
-USA/CAN
115 / 60
