Specifications

Speaker
Voice coil Ø
SPL @ 1m /
1W
Frequency
Response
(-10dB)
Impedance
Power
25W (RMS)
Rating
Input-RCA and
φ6.3 Balanced /
Connector
Output-link φ6.3
Power AC220-240V~ /
Supply
Dimensions
115x107x175mm
(WxDxH)
Weight

BLOCK DIAGRAM

WMS3A
3" (77x77mm) Paper cone
0.8" (20.4mm)
85dB (±3dB)
132Hz-20KHz
6Ω/70V:245Ω /
500Ω / 1KΩ / 2KΩ
4Ω
100V:500Ω / 1KΩ
/ 2KΩ
6Ω/70V: 20W /
10W /5W / 2.5W
100V: 20W/10W
/5W
Wiring terminal
Jack
50Hz
115x107x175mm
1.33 kg
WMS3P WMS4A
88Hz-18KHz
40W (RMS)
Input-RCA and
φ6.3 Balanced /
Output-link φ6.3
AC220-240V~ /
136x140x206mm
1.18kg
WMS4P
4" (102mm) Paper cone
1" (25.4mm)
90dB (±3dB)
76Hz-18kHz
6Ω/70V: 122Ω /
250Ω / 500Ω /
4Ω 1000Ω
100V:250Ω / 500Ω
/ 1000Ω
6Ω/70V:40W/20W
/10W / 5W
100V:40W/20W
/10W
Wiring terminal
Jack
50Hz
136x140x206mm
2.4 kg 2.3kg
