1. MULTIFUOCO 2003 VENTILATION KIT WITH
RADIO CONTROL
The stoves are designed for installing the "Multifuoco 2003 Ventilation kit with radio control. This system, patented
by Gruppo Piazzetta S.p.A., makes it possible to heat one or more rooms uniformly thus preventing layering of hot
air near the ceiling.
Installation of the fan kit does not entail an increase in the heat output of the appliance, but rather the
uniform heating of the room (or rooms), since this system (allowing air intake from above and outflow from below)
creates a recycling of hot air which impedes ceiling stratification.
3
The Fan kit consists of: a fan (with airflow of approx. 220 m /h and 47 watt capacity) complete with cable and radio
control box; PT probe; portable radio control with 4 buttons (powered by low-voltage batteries); spacers; small parts
for fixing.
The remote control has an ON/OFF button with two functions, i.e. "on / off", a button for switching to automatic
operation (AUTO) and two buttons (+/-) governing the fan operating speed (minimum speed V1, medium speed V2,
maximum medium speed V3, maximum speed, V4).
To identify the fan operating speed setting, simply listen to the number of beeps emitted when pressing the + and -
buttons of the remote control (1 beep for each increase in speed); when manually shutting off the fan, a long
beep indicates that the system has been turned off.
The probe allows the fan to start and stop automatically when the temperature reaches the turn-on and turn-off
thresholds.

REMOTE CONTROL
