1.1.7 Video Analysis Page

The device can be configured to emit motion
detection alarms using ONVIF events.
This page allows you to define the following settings:
• Enable emission of motion detection events.
• Configure the algorithm sensitivity level.
Fig. 14

1.1.8 Wash System Page

Do not use the wiper if the outside
temperature is below 0°C or in case of ice.
From the menu, it is possible to configure the device
wash system functions.
Fig. 15
6

1.1.9 Digital I/O Page

From menu entry Digital I/O it is possible to configure
the Digital Input and Output channels available in the
device.
• Digital Inputs: The status of the alarms can be
monitored thanks to the icon on the page. In
normal conditions, the icon will be green, while it
turns red if an alarm is detected.
• Digital Outputs: Using the Disable Relay/Enable
Relay buttons, you can force the output status.
The function DIgital Output is only valid if
the wash system is disabled.
• Disables the Relay/Enables the Relay
Fig. 16
Fig. 17
