The large feed compartment is also used
when the material is to be cut in a defi nite
direction, such as tomatoes and lemons.
Place/stack the products as shown in the
fi gure (2:B).
The feed tube is used for cutting long
products such as cucumbers (2:C).
CLEANING
Switch off the machine and remove the
power supply plug from the socket or open
the isolating switch.
Carefully clean the machine immediately
after use.
If you have used a dicing grid (3:G), leave
it in the machine, and use the brush (4:N)
for pushing out any product remaining in the
grid.
Remove the loose parts of the machine,
wash them and dry them thoroughly.
Never wash light metal items in the
dishwasher unless they are marked
"diwash".
If the cutting tools are marked "diwash",
read and follow the special "diwash" user
instruction manual carefully.
Wipe the machine with a damp cloth.
Always wipe the knives of the cutting tools
dry after use.
Always store the cutting tools (3) on the
hangers (4:M) on the wall.
Never use sharp objects or a high-pressure
spray gun for cleaning.
Never spray water on the sides of the
machine.
CHECK EVERY WEEK
That the machine stops as soon as the
pusher plate (1:A) has been moved up
and swung out, and that it restarts when
the pusher plate has been swung in and
lowered.
That the machine cannot be started with
the feeder/lid (1:C) removed and with the
pusher plate lowered.
Remove the plug from the power supply
socket or open the isolating switch, and
then check that the electric cable is in good
condition and is not cracked on the outside.
If any of the two safety functions does not
perform as intended or if the electric cable
is cracked, get a specialist to attend to the
machine before connecting it back to the
power supply.
Check that the pusher plate shaft (1:I) has
been lubricated as necessary and runs
freely. If the shaft does not run freely, clean
it carefully and lubricate it with a few drops
of machine oil.
Check that the knives and shredder plates
are in good condition and are sharp.
TROUBLE-SHOOTING
FAULT: The machine cannot be started,
or stops while it is running and cannot be
restarted.
REMEDY: Check that the plug is securely
fi tted into the power supply socket, or that
the isolating switch is closed. Check that the
feeder/lid (1:C) and the pusher plate shaft
(5:I) is locked in the correct position. Move
down the pusher plate into the feeder/lid.
Check that the fuses in the fuse box for the
premises have not blown and that they have
the correct rating. Wait for a few minutes
and try to restart the machine. If the machine
still fails to run, call a specialist.
FAULT: Low capacity or poor cutting results.
REMEDY: Make sure that you are using
the correct cutting tool or combination of
cuttings tools (3). Fit the Hallde cabbage
driver (1:J). Check that the knives and
shredder plates are in good condition and
are sharp. Press the food down loosely.
FAULT: The cutting tool (3) cannot be
removed.
REMEDY: Always use the ejector plate (1:
D). Use a thick leather glove or the like that
the knives of the cutting tool cannot cut
through, and turn the cutting tool clockwise
to release it.
FAULT: The Hallde cabbage driver (1:J )
cannot be removed.
REMEDY: Use the spanner (1:K) to unscrew
the Hallde cabbage driver clockwise.

TECHNICAL SPECIFICATION

MACHINE: Motor: 0.55 kW. 100 V, single-
phase, 50-60 Hz. 1 10-120 V, single-phase,
60 Hz. 220 V, single-phase, 50 Hz.
230-240 V, single-phase, 50 Hz. 230 V,
three-phase, 50 Hz. 400 V, three-phase,
50 Hz. 440 V, three-phase, 60 Hz. With
thermal motor protection. Transmission:
gears. Safety system: Two safety switches.
Degree of protection machine: IP44.
Degree of protection push buttons: IP65.
Power supply socket: Earthed, single-phase,
10 A, or 3-phase, 16 A. Fuse in fuse box for
the premises: 10 A, slow-blow. Sound level
LpA (EN31201): 72 dBA.
TOOLS: Diameter: 185 mm. Speed: 350
rpm (50 Hz), 420 r.p.m. (60 Hz).
MATERIALS: Machine housing and feed
cylinder: Anodized or polished aluminium
alloy. Cutting tool discs: Aluminium alloy or
acetal. Cutting tool knives: Knife steel of the
highest quality.
NET WEIGHTS: Machine: 21 kg. Cutting
tools: About 0.5 kg on average.
STANDARDS: EU Machine Directive
89/392EEC .
