HANSGROHE Rainmaker Gebrauchsanleitung, Montageanleitung Seite 7

Water connection DN 20
Warm water
Water connection DN 20
Cold water
Robinet d'arrêt encastré
Quattro 4-Way Diverter Valve
Quattro
Trio 2-Way Diverter Valve with
integrated Shut-off valve
Trio
High Thermostatic mixer HighFlow
Flow
From • the function is guaranteed.
The waste drain performance must be
more than 50 l/min.
> 50 l/min
Waste
Raindrain
X
Center shower tub
English
Turn on water
turn off water
Installation sequence
1.
Silicone (free from acetic acid!)
Wiring conduit for power supply
cable
Grease
Hot surface!
Safety gloves must be worn
Eye protection must be worn
natural sponge
Decalcifier (Citric acid base)
Avoid contact with eyes and skin. If
this product contacts your eyes, rinse
thorougly with water.
QUICK
The QuickClean cleaning function
only needs a small manual rub over
CLEAN
to remove the lime scale from the
spray channels.
Assembly see page 60
Electricity on / off
Electricity on / off
Potential equalisation
N
neutral conductor
L
conductor
FI protective switch
FI
junction box
light switch
transformer
connectors
distributor box
Illuminant
