Technical data

General
IP
Max. ambient RH (relative humidity)
Thermostat and timer
CE marking
ERP (thermostat only)
Low voltage tests
EMC (electromagnetic compatibility requirements) tests
Power supply
Voltage
Operating temperature
Storage temperature
Connection terminals (I-143, T-143, T-144, T-145, T-146, and T-148)
Connection terminals (T-149)
Controller
CE marking
ERP
Low voltage tests
EMC (electromagnetic compatibility requirements) tests
Power supply
Internal fuse
Operating temperature
Storage temperature
Maximum consumption
Pump and boiler relay outputs
General purpose input (GPI)
Valve outputs
Power connection
Connection terminals for power, pump, GPI and boiler
Connection terminals for bus communication
Connection terminals for valve outputs
*) EN 60730-1 Automatic electrical controls for household and similar use
-- Part 1: General requirements
**) EN 60730-2-1 Automatic electrical controls for household and similar use
-- Part 2-1: Particular requirements for electrical controls for electrical
household appliances
***) EN 60730-2-9 Automatic electrical controls for household and similar use
-- Part 2-9: Particular requirements for temperature sensing controls
U P O N O R S M AT R I X B A S E · Q U I C K G U I D E
QUICK GUIDE
IP20 (IP: degree of inaccessibility to active parts of the product
and degree of water)
85% at 20 °C
IV
EN 60730-1* and EN 60730-2-9***
EN 60730-1
From controller
4.5 V to 5.5 V
0 °C to +45 °C
-10 °C to +70 °C
0.5 mm² to 2.5 mm²
0.25 mm² to 0.75 mm² solid, or 0.34 mm² to 0.5 mm² fl exible
with ferrules
IV
EN 60730-1* and EN 60730-2-1**
EN 60730-1
230 V AC +10/-15%, 50 Hz or 60 Hz
T5 F3.15AL 250 V, 5x20 3.15A quick acting
0 °C to +45 °C
-20 °C to +70 °C
40 W
230 V AC +10/-15%, 250 V AC 8 A maximum
Only dry contact
24 V AC, 4 A max.
1 m cable with europlug (except UK)
Up to 4.0 mm² solid, or 2.5 mm² fl exible with ferrules
0.5 mm² to 2.5 mm²
0.2 mm² to 1.5 mm²
Usable in all Europe
Declaration of conformity:
We hereby declare under our own responsibility that products dealt
with by these instructions satisfy all essential demands linked to the
information stated in the Safety instruction booklet.
