GB
net
4NBL
4BL
3NBL
3BL
2BL
1BL
Ct
MaX
tiMe 4i
tiMe P
rSeT
MaX P
ea
eR
aUX
baCLit
SOFt
THD i1, i2, i3
THD U12, U23, U31
THD V1, V2, V3
Network type
Unbalanced three-phase network, 4 wires with 3 or 4 TC
Balanced three-phase network, 4 wires with 1 TC
Unbalanced three-phase network, 3 wires with 2 or 3 TC
Balanced three-phase network, 3 wires with 1 TC
Two-phase network, 2 wires with 1 TC
Single-phase network, 2 wires with 1 TC
Current transfromers
Maximum mean value
integration times for maximum current values
integration times for maximum power values
Reset
active power maximum mean value
active power (kwh)
Reactive power (kvarh)
auxiliary supply
LCD start-up (U or i or aux. Condition)
Serial number
Software version
Current harmonic distortion rate
Phase-to-phase voltage distortion rate
Phase-to-neutral voltage distortion rate
