146 68
CARACTéRISTIQuES TEChNIQuES
TEChNICAl ChARACTERISTICS - TEChNISChE DATEN -
CARATTERISTIChE TECNIChE - TEChNISChE EIGENSChAPPEN -
CARACTERíSTICAS TéCNICAS - CARACTERíSTICAS TéCNICAS
GB
CASE
Dimensions:
Connection:
iP index:
weight:
DISPLAy
Type :
MEASUREMENTS
Three-phase (3 or 4 wires), two-phase (2 wire) and single-phase networks
VOLTAGE (TRMS)
Direct measurement:
Permanent overload:
Update period:
CURRENT (TRMS)
Via CT with:
Minimum measuring current
input consumption:
Display:
permanent overload:
intermittent overload:
Update period:
POWER
Total:
Update period:
FREQUENCy
Update period:
AUXILIARy SUPPLy IEC/CE
110 to 400 V aC 50/60 Hz
120 to 350 V DC
Consumption:
146 68 - Ref.: N292510/02
42
96 x 96 x 60 mm
or 96 x 96 x 80 mm with all optional modules (DiN 43700)
via 2.5 mm
disconnectable terminals
2
(voltage and others) and 6 mm
iP52 (front panel) and iP30 (case)
400 gr.
backlit LCD display
from 50 to 500 V aC (phase/phase)
from 28 to 289 V aC (phase/neutral)
800 V aC
1 second
• Primary:
up to 9 999 a
• Secondary:
5 a
5 ma
< 0.6 Va
from 0 to 11 ka (1.1 times the primary value)
6 a
10 in / 1 second
1 second
0 to 11 Mw/Mvar/MVa
1 second
from 45,0 to 65,0 Hz
1 second
± 10 %
± 20 %
< 10 Va
fixed terminals (current)
2
