INSTAllATIoN
INSTAllATIoN - INSTAllATIoN - INSTA llAzIoNE -
INSTA llERING - INSTA lACIóN - INSTA lAção
RéSEAu BIPHASÉ (2BL)
GB
Two-phase network (2bl)
D
zweiphasennetz (2bl)
I
Rete bifase (2bl)
NL
Tweefasennet (2bl)
E
Red bifásica (2bl)
P
Rede bifásica (2bl)
RéSEAu MONOPHASÉ (1BL)
GB
Single-phase network (1bl)
D
Einphasennetz (1bl)
I
Rete monofase (1bl)
NL
Enkelfasenet (1bl)
E
Red monofásica (1bl)
P
Rede monofásica (1bl)
146 68 - Ref.: N292510/02
16
I1 I2 I3
S1 S2 S1 S2 S1 S2
S1
P1
1 Aux.: ieC /Ce
2 Fus.: 0.5 A gG / BS 88 2A gG / 0.5 A class CC
I1 I2 I3
S1 S2 S1 S2 S1 S2
S1
P1
1 Aux.: ieC /Ce
2 Fus.: 0.5 A gG / BS 88 2A gG / 0.5 A class CC
V1 V2 V3 VN AUX
2
1
2
L1 ( R )
L2 ( S )
110... 400V aC
120... 350V DC
V1 V2 V3 VN AUX
2
1
2
L1 ( R )
N
110... 400V aC
120... 350V DC
