Rear Panel - ASROCK X399 Taichi Bedienungsanleitung

• Premium Blu-ray Audio support
• Supports Surge Protection (ASRock Full Spike Protection)
• Supports Purity Sound
- Nichicon Fine Gold Series Audio Caps
- 120dB SNR DAC with Differential Amplifier
- TI® NE5532 Premium Headset Amplifier for Front Panel
Audio Connector (Supports up to 600 Ohm headsets)
- Pure Power-In
- Direct Drive Technology
- PCB Isolate Shielding
- Impedance Sensing on Line Out port
- Individual PCB Layers for R/L Audio Channel
- Gold Audio Jacks
- 15μ Gold Audio Connector
• Supports DTS Connect
• Gigabit LAN 10/100/1000 Mb/s
LAN
• 2 x GigaLAN Intel® I211AT
• Supports Wake-On-LAN
• Supports Lightning/ESD Protection
• Supports Energy Efficient Ethernet 802.3az
• Supports PXE
• Intel® 802.11ac WiFi Module (Free Bundle)
Wireless
• Supports IEEE 802.11a/b/g/n/ac
LAN
• Supports Dual-Band (2.4/5 GHz)
• Supports high speed wireless connections up to 433Mbps
• Supports Bluetooth 4.2 / 3.0 + High speed class II
• 2 x Antenna Ports

Rear Panel

• 1 x PS/2 Mouse/Keyboard Port
I/O
• 1 x Optical SPDIF Out Port
• 1 x USB 3.1 Type-A Port (10 Gb/s) (Supports ESD Protection)
• 1 x USB 3.1 Type-C Port (10 Gb/s) (Supports ESD Protection)
• 8 x USB 3.0 Ports (Supports ESD Protection)
* Ultra USB Power is supported on USB3_6 port.
* ACPI wake-up function is not supported on USB3_6 port.
TM
4
X399 Taichi
7
