Model Assembly
2.Attach the ball link to the elevator control horn's outermost hole
using the included linkage rod as shown.
Vertical Stabilizer Installation
1.Carefully apply CA to the top rear fuselage slot. Install the
vertical stabilizer into place.
Notice: The connectors on both side should be attached precisely
and firmly.
Ventral Fin Installation
1.Carefully apply CA to the bottom rear fuselage slot. Install the
ventral fins into place.
Note: 1. Ensure the higher side goes towards the front of the
plane.
2.The fins will angle towards the outboard of the plane as
shown.
Required Adhesives:
Foam Safe Medium CA
Required Adhesives:
Foam Safe Medium CA
