FULL FACE MASKS [EN]
INFORMATIONS SUPPLIED BY THE MANUFECTURER: USER
LEAFLET INSTRUCTIONS FOR USE AND MAINTENANCE OF BLS
FULL FACE MASKS. PREFACE These instructions refer to the BLS
series of full face masks: BLS 5150 BLS 5400, BLS 5250 BLS 5500,
3150, 3150V 3400, BLS 5600 BLS 5700. The BLS full face masks must
be used and maintained in accordance with the following instructions
as far as the use, the limitations and the maintenance are concerned.
Incorrect use, use of unsuitable spare parts or bad maintenance is
dangerous for health and safety and invalidates the guarantee
exonerating the manufacturer from all liability. It has to be stressed that
personal protective equipments for respiratory protection must always
be used by specially trained people, supervised by a person perfectly
aware of the limits of application of those devices and of the laws that
are in being in the Country concerned. Warning If you lose this leaflet
or if you require further copies, please contact the address below and
quote this code number: ISU 031_00.The product has been examined
at the design stage by Italcert, Milano – Italia (0426). These full face
masks have shown to meet the health and safety certification
requirements under the art.10 and art.11B of DIR 89/686/CEE. The
BLS full face masks are CE marked and have been tested according to
the EN 136:1998 standard's requirements. BLS Srl Via Morghen, 20 –
20158 Milano – Italy Tel +39 02.39310212 Fax +39 02.66200473 e-
mail: info@blsgroup.it www.blsgroup.it
1 – GENERAL
1.1
Description BLS manufacture the following models of full face
masks
Model Class Filters used
BLS 5150 3 1
threaded
BLS 5400 3 1
threaded
BLS 5250 2 2 filters TP2000 threaded
BLS 5500 2 2 filters TP2000 threaded
3150 2 1
threaded
3150V 2 1
threaded
3400 2 1
threaded
BLS 5600 2 Special bayonet
BLS 5700
2 Special bayonet
The full face masks of BLS 5000 series with the EN 148-1 connection
are classified according to the EN 136:1998 standard into class 3 (full
face mask for special use) and are composed by:
•
External face seal Synthetic rubber (BLS 5150), silicone (BLS 5400)
•
Extra wide panoramic visor moulded in polycarbonate
Frontal component which is a support for the exhalation valve with
its holder
Inner mask to reduce dead space moulded in silicone provided with
two air circulation valves which prevent the visor from the steaming
up and towards the formation of an excessive carbon dioxide level
in the exhaled air
Head harness with six straps, moulded in synthetic rubber with
quick fastening buckles
collar for wearing the mask around the neck during the breaks (only
for BLS 5400 model)
The full face masks of BLS 5000 series with two filters BLS 300 are
classified according to the EN 136:1998 standard into class 2 (full face
mask for general use) and are composed by:
•
External face seal Synthetic rubber (BLS 5250), silicone (BLS 5500)
•
Extra wide panoramic visor moulded in polycarbonate
Frontal component which is a support for the exhalation valve
Two lateral filter holders with special BLS 300 filters connection
Inner mask to reduce dead space moulded in silicone provided with
two air circulation valves which prevent the visor from the steaming
Face seal material
filter EN 148-1 Synthetic rubber
filter EN 148-1 Silicone Rubber
Synthetic rubber
Silicone Rubber
filter EN 148-1 Natural Rubber
(polycarbonate
Visor)
filter EN 148-1 Natural Rubber
(glass visor)
filter EN 148-1 Silicone Rubber
(polycarbonate visor)
Rubber
Silicone
up and towards the formation of an excessive carbon dioxide level
in the exhaled air
Head harness with six straps, moulded in synthetic rubber with
quick fastening buckles
collar for wearing the mask around the neck during the breaks (only
for BLS 5500 model)
The full face masks of 3000 series with the EN 148-1 connection are
classified according to the EN 136:1998 standard into class 2 (full face
mask for general use) and are composed by:
•
Face seal Natural rubber (3150, 3150V), silicone rubber (3400)
•
Extra wide panoramic visor moulded in polycarbonate (3150, 3400)
or glass (3150V)
Frontal component which is a support for the exhalation valve
Inner mask to reduce dead space moulded in silicone provided with
two air circulation valves which prevent the visor from the steaming
up and towards the formation of an excessive carbon dioxide level
in the exhaled air
Head harness, moulded in rubber with quick fastening buckles
The full face masks of BLS 5000 series with the bayonet connection
are classified according to the EN 136:1998 standard into class 2 (full
face mask for general use) and are composed by:
•
External face seal Synthetic rubber (BLS 5600), silicone (BLS 5700)
•
Extra wide panoramic visor moulded in polycarbonate
•
Frontal component which is a support for the exhalation valve
Two lateral filter holders with special bayonet connection
Inner mask to reduce dead space moulded in silicone provided with
two air circulation valves which prevent the visor from the steaming
up and towards the formation of an excessive carbon dioxide level
in the exhaled air
Head harness with six straps, moulded in synthetic rubber with
quick fastening buckles
The one size full face masks are designed to achieve a perfect seal
with no vexatious pressures on the most of the face shapes.
1.2 Drawing and components list See the expanded drawing of the
BLS masks reported on last page. Component list: See Table1
1.3 Applications The full face masks of this series can be used in
conditions that require protection for both eyes and respiration. They
are particularly recommended for toxic and/or hazardous substances.
The full face mask BLS may be used with gas, particle and combined
filters. For a correct use and choice of the gas filters see the provided
instruction leaflet.
1.4 Selection of breathing protector equipped with filter To select
this kind of personal protective devices it is necessary to consider the
following indicators: NPF (nominal protection factor) is the value came
from the maximum percentage of total inward leakage allowed by the
relevant European standard (NPF = 100/ % maximum total inward
leakage admitted). APF (assigned protection factor) is the level of
respiratory protection that can realistically be expected to be achieved by
correctly fitted respirator (it is different for each State). TLV (threshold
limit value) is a concentration threshold - generally expressed in parts per
million, ppm – for the safety of the people exposed to dangerous
substances. The APF multiplied by the TLV of the substance gives the
concentration of pollutants to which an operator can be exposed wearing
a specific device. For the selection and maintenance of the filtering
devices and for the definition and use of APF and NPF also refers to the
European Standard EN 529 and to the relevant national regulations.
APF summarizing table
APF
Type of
protectiv NPF
I FIN
e device
Full face 5 4 4
mask
with
particle
filter P1
Remarks,
limitations
D S UK
4 4 4 Not advisable
as the high
penetration
through
filter increases
the
Inward
the
Total
2
