I/O Panel
1
14
No. Description
1 USB 2.0 Ports (USB12)
2 DisplayPort 1.1a
3 LAN RJ-45 Port*
4 Central / Bass (Orange)
5 Rear Speaker (Black)
6 Line In (Light Blue)
7 Front Speaker (Lime)**
2
13 12
No. Description
8
9
10
11
12
13
14
3
11 10
Microphone (Pink)
Optical SPDIF Out Port
USB 3.0 Ports (USB3_12)
USB 3.0 Ports (USB3_56)
HDMI Port
DVI-D Port
PS/2 Mouse/Keyboard Port
N3700-ITX
N3150-ITX
4 6
5 7
9 8
3
