Specifications - Weber Style 6438 Handbuch

DigiTal ThermomeTer
Notes:
• P lace the ThermoSensor away from direct heat or flame and do not rest the probe on
the cooking surface. Doing so could damage the thermistor inside the probe.
• For a clear signal, place the monitor within 100 feet of the ThermoSensor.
• T he operation temperature range of the sensor probe is -4°F to 482°F (20°C to 250°C). The LCD
display range is 0°C/F to 199°C/F. When the display temperature is out of range, the display's
digits flash.
4. When the meat is done, remove the probe from the meat wearing an oven mitt or let the
probe cool off. Press and hold POWER on the monitor and ThermoSensor for about 2
seconds to turn them off.
Notes:
• T he monitor's last record remains even when you turn the power off. When you turn the
monitor on again, the last record appears on the display.
• T he monitor and ThermoSensor automatically turn off it you do not press any button for
about eight hours.
5. Disconnect the probe from the ThermoSensor and replace the socket cover. After you
finish cooking, clean the probe with water and a mild detergent. Wipe the monitor and
ThermoSensor with a damp cloth.
Note: Do not use a dishwasher to clean the probe or immerse the monitor or
ThermoSensor in water or liquid.
CHECKING SIGNALS AND AUDIBLE ALARM STATUS
SIGNAL
Indicates no signal.
ALERTS
Three beeps - indicates the monitor in not receiving a signal from the ThermoSensor.
Four beeps - indicates the current temperature is within five degrees of the target temperature.
A continuous beep - indicates the thermometer has reached its target temperature.
A fast and continuous beep - indicates the meat is overcooked.
Note: Press any button to stop the alert.
BATTERY NOTES
appears on the monitor to indicate the condition of the batteries. The following alerts indicate
when the batteries need to be replaced.
• main - indicates the monitor's battery is low.
• remote - indicates the ThermoSensor's battery is low.
• main remote - indicates the batteries are low in both the monitor and
ThermoSensor.
• Use only fresh batteries of the required size and recommended type.
• D o not mix old and new batteries, different types of batteries (standard, alkaline or rechargeable)
or rechargeable batteries of different capacities.
• If you do not plan to use the thermometer with batteries for a month or more, remove the
batteries. Batteries can leak chemicals that can destroy electronic parts.
178715_0710.indd 3
Indicates the monitor is receiving a signal from
the ThermoSensor.
Weber-Stephen Products Co., (Weber ) hereby warrants to the ORIGINAL PURCHASER of
®
this Digital Thermometer, that it will be free from defects in material and workmanship from
the date of purchase as follows: 2 year(s) when assembled, and operated in accordance with
the printed instructions accompanying it.
Weber may require reasonable proof of your date of purchase. THEREFORE, YOU SHOULD
RETAIN YOUR SALES SLIP OR INVOICE AND RETURN THE WEBER LIMITED WARRANTY
REGISTRATION CARD IMMEDIATELY.
This Limited Warranty shall be limited to the repair or replacement of parts that prove defective
under normal use and service and which on examination shall indicate, to Weber's satisfaction,
they are defective. If Weber confirms the defect and approves the claim, Weber will elect
to repair or replace such parts without charge. If you are required to return defective parts,
transportation charges must be prepaid. Weber will return parts to the purchaser, freight or
postage prepaid.
This Limited Warranty does not cover any failures or operating difficulties due to accident,
abuse, misuse, alteration, misapplication, vandalism, improper installation or improper
maintenance or service, or failure to perform normal and routine maintenance. Deterioration or
damage due to severe weather conditions such as hail, hurricanes, earthquakes or tornadoes,
discoloration due to exposure to chemicals either directly or in the atmosphere, is not covered
by this Limited Warranty.
Weber shall not be liable under this or any implied warranty for incidental or consequential
damages. This warranty give you specific legal rights, and you may also have other rights,
which vary from state to state.

SPECIFICATIONS

Monitor
Batteries 2 x AA
Operating temperature range
32°F to 122°F (0°C to 50°C)
Storage temperature range
-4°F to 158°F (20°C to 70°C)
Water Resistance JIS Level 2
LCD Display Range
General
Length of stainless steel probe
Transmit frequency
Temperature resolution
Steel sensor probe's operating temperature
Specifications are typical; individual units may vary. Specifications are subject to change and
improvement without notice.
ThermoSensor
Batteries 2 x AAA
Operating temperature range
-4°F to 140°F (20°C to 60°C)
Storage temperature range
22°F to 158°F (-30°C to 70°C)
Water resistance JIS Level 3
0°C/F to 199°C/F
99.97cm (3.28 feet)
433MHz
+1°C (+- 2°F)
Maximum 250°C (482°F)
3
