1
MAIN LEVEL ADJUST
Preset of the level.
2
LIMIT, SIGNAL, POWER LED
LIMIT LED: flashes RED when the integrated limiter is active.
SIGNAL LED: flashes green when a signal is detected. Turns off when limiter is active.
POWER LED: flashes green if device is turned to ON.
3
INPUT XLR / 6.3 mm jack (LEFT / RIGHT)
Symmetrical Line Input for XLR connectors and 6.3 mm jacks.
4
LINE DIRECT OUTPUT (LEFT / RIGHT)
Direct, symmetrical Line Output for XLR connectors.
5
POWER SWITCH
ON / OFF switch. Please switch connected devices to ON first and to OFF after switching the system.
6
POWER CONNECTION SEAT
Power connection seat 240 V (IEC power connector) and fuse seat. Replacement of fuse only if power con -
nection is disconnected. If fuse blows repeatedly please contact authorized personel for servicing.
7
MAIN THROUGH SEAT
Power connection seat 240 V (IEC power connector) for direct power supply forwarding (for additional
LD MON 121 A).
ConneCtion & OperatiNg eLeMeNtS:
07
