Safety warnings
or discomfort occurs. The vapours
may cause respiratory irritation.
The lithium-ion rechargeable bat-
■
tery can be recharged at any time
without shortening its lifespan. In-
terrupting the charge cycle will not
damage the rechargeable battery.
When taking out of use for a long
■
time, put the tool away with bat-
tery charged. This will prolong the
life of the lithium-ion rechargeable
battery.
When not in use, keep the
■
rechargeable battery away from
paper clips, coins, keys, nails,
screws or other small metal
objects that could short-circuit
the contacts. Short-circuiting the
rechargeable battery contacts can
cause burns or fire.
Do not short-circuit the recharge-
■
able battery. It could explode.
Make sure the tool is switched
■
off before fitting the rechargeable
battery. Inserting a rechargeable
battery into a power tool that is
switched on can lead to acci-
dents.
Only charge rechargeable batter-
■
ies in chargers recommended by
the manufacturer. A charger suita-
ble for specific rechargeable bat-
teries presents a risk of fire if it is
used for charging other recharge-
able batteries. Only use recharge-
able batteries intended for use
in power tools. The use of other
rechargeable batteries can result
in injuries and the risk of fire.
Protect the rechargeable battery
■
from moisture and water. Charge
the rechargeable battery at a tem-
perature ranging from 0 °C to
45 °C. Do not, for example, leave
the rechargeable battery inside a
car during summer. From time to
time, clean the rechargeable bat-
tery's ventilation slots with a soft,
clean and dry paintbrush.
Transport
The rechargeable battery con-
■
forms to UN manual ST/SG/AC.
10/11/Rev.3 Part III, sub-section
38.3. It is equipped with an effec-
tive means to prevent internal
pressure build-up and short circuit
as well as a means to preclude
violent rupture and dangerous
reverse current flow. The lithium-
equivalent quantity contained in
the rechargeable battery is below
the relevant limit values. Therefore,
the rechargeable battery is not
subject to national or international
dangerous goods regulations ei-
ther as an individual component or
fitted in a device. However, these
regulations may become relevant if
transporting several rechargeable
batteries. In this case, it may be
necessary to observe specific
conditions (e.g. in relation to
packaging).
– 14 –
Safety warnings
When not in use and for transpor-
■
tation remove the battery from
the device. For storage place the
battery in the slot provided.
Proper use
The STEINEL BHG 360 li-ion power tool is intended for shap-
■
ing and welding plastic as well as for heating shrink tubing.
It can also be used for soldering and tin-plating as well as
ungluing bonded joints.
For your safety
The thermal cut-out shuts the tool down if it is overloaded.
Tool features
1
Stainless steel outlet nozzle
2
Air inlet with lattice guard keeps out foreign matter
3
Ergonomic soft grip handle
4
Three-stage switch with OFF/COLD/HOT settings.
5
LED light for illuminating the work area
6
Hanging ring
7
Reduction nozzle, 7 mm
8
Rechargeable battery release button
* Some of the accessories illustrated or described are not included as standard.
Using the LS - 36 V charge station
Observe mains voltage: The voltage of the power source must
match the specifications shown on the type plate of your hot air
tool. Tools showing 230 V can also be operated on 220 V.
The charge cycle begins as soon as the charger is plugged in
13
and the rechargeable battery is inserted into the charging
10
slot .
What the indicators mean
Charge cycle monitoring is signalised by LED indicators
Fast charge mode
The fast charge mode is signalised by the flash-
ing green LED indicator 12 . While charging,
the 3 green LEDs on the rechargeable battery
light up in succession and then briefly go out.
The rechargeable battery is fully charged when
the 3 green LEDs are permanently lit. The 3 green
LEDs go out again about 5 minutes after the recharge-
able battery has been fully charged.
The fast charge mode is only possible when the rechargeable
battery is at a temperature of between 0 °C and 45 °C.
Keep these safety warnings in a
safe place together with the tool.
The LS - 36 V charger is only suitable for charging the
■
STEINEL li-ion 10 IMR 18/65-2 rechargeable battery
(type 0938).
9
Charging station.* LS - 36 V (type 0939)
10
Charging slot
11
Red LED charging indicator
12
Green LED charging indicator
13
36V rechargeable battery: STEINEL li-ion 10 IMR 18/65-2
(type 0938)
14
Button for state-of-charge indicator
15
Temperature monitoring indicator
16
Rechargeable battery state-of-charge indicator
The intelligent charging process automatically identifies the
charge state of the rechargeable battery and charges it with the
charge current optimised for battery temperature and voltage.
This protects the rechargeable battery and always keeps it fully
charged when kept in the charger.
11 12
or :
Battery charged
Green LED indicator 12 lights up permanently
to signalise that the rechargeable battery is
fully charged. An acoustic signal lasting approx.
2 seconds is also given to signalise that the
rechargeable battery is fully charged.
The rechargeable battery can now be removed
for immediate use.
When the rechargeable battery is not inserted, the green LED
indicator 12 lights up permanently to signalise that the charger
is plugged into the power supply and ready for use.
